The Xtreme Bar completely upends the light bar market with unmatched versatility and extreme performance. Available in sizes from 4” to 20” in length, these compact light bars fit where others don’t dare to venture such as small grille and bumper openings. Not only are Xtreme Bar light bars more powerful than most offroad lights, but the precise beam pattern is also compliant with DOT standards and is completely street legal.

FEATURES + SPECIFICATIONS

• Light Output: 1,200-8,900 lm
• Power: 20-110W @ 13.6V DC
• Current: 1.5-11 A @ 13.6V DC
• Voltage: 9- 48V DC
• Widths Available: 4″, 5”, 8″, 12”, 20”
• Beam Patterns Available:
       • Fog + Strobe Light
       • Auxiliary High Beam
       • Auxiliary High Beam + Fog + Strobe
• Compliance Available: SAE J581, J583
• Warranty: 5 years
4” DRIVING BEAM 6401D White
Effective Lumens 1,800 lm
Power 20W
Dimensions 4.8 x 2.6 x 1.6”
4” Fog Beam 6401F Dual Color
Effective Lumens 1,200 lm
Power 20W
Dimensions 4.8 x 2.6 x 1.6”
5” Driving Beam 6403D Dual Color
Effective Lumens 2,000 lm
Power 20W
Dimensions 5 x 2.5 x 1.5”
8” Driving Beam 6402D(White)/6402DT(White)/6402YT(Yellow)
Effective Lumens 3,400 lm
Power 45W
Dimensions 7.8 x 2.6 x 1.6”
12” Driving Beam 62101(White)/62102(Yellow)
Effective Lumens 3,400 lm
Power 60W
Dimensions 12 x 1.8 x 1.5”
20″ DRIVING BEAM 64033 Dual Color
Effective Lumens 8,900 lm
Power 110W
Dimensions 19.7 x 2.8 x 1.5”
