Work Bar Strobe 4, 4″ Surface Mount, Amber/Blue (1EA) – BB6010C

MSRP $85.99 USD

BUILTBRIGHT® Work Bar Strobe 4 delivers a powerful light in a slim, compact design. Available in single & dual color options to meet any need to customize your vehicle or fleet. The unit houses twelve premium quality 3W LEDs with linear optics to magnify the flash, with 54 flash patterns in dual color options. Three (3) user programmable memory modes allows you to preset three (3) different patterns based on your customized choice.

The Work Bar Strobe 4 features a strong polycarbonate lens on an aluminum body and an aluminum protective bezel to maximize protection from debris impact and to absorb heat dispersion. This product can be fitted virtually anywhere on a vehicle in a fit-and-forget-it fashion. Boasting major industry requirements such as IP69K, SAE Class I and EMC R10, the product is backed with a 5 year warranty.

WHERE TO BUY
SKU: BB6010C Categories: ,

Compliance: SAE J595 Class I, California Title 13, ECE R65, and R10
LED Count: 12
Voltage: 12~24 V DC
Flash Patterns: 54
Max Current: 0.9A
Max Power: 9W
Wires: 5 Core (22 AWG)
Wire Length: 28 Inch
LED Colors: Dual Color (Amber & Blue)
Working Temp: -40°F to + 149°F
Weatherproof Rating: IP69K
Dim: 0.94“ H x 4.9”L x 0.79” D
Connector(s): Waterproof male & female connectors with pigtail
Lens Material: Ultra-strong UV stabilized polycarbonate lens
Housing Material: Cast Aluminum Powder Coated Black
Hardware Material: 304 Stainless Steel
Bezel Material: Polycarbonate
Warranty: 5 Year

● 12 and 24 VDC compatible
● Meets SAE J595 Class I, California Title 13, ECE R65, and R10 requirements
● 12 high-intensity LEDs behind a proprietary optical lens
● 3 user-programmable modes
● Dual color: Amber and Blue
● 54 flash patterns
● Multi-unit synchronization in simultaneous or alternating flash
● Low-profile design with aluminum mounting bezel
● Waterproof connectors included
● Compatible with StrobeLink™ Harness
● Weatherproof, IP69K rated

● 1 x LED Lamp
● 1 x Foam Pad
● 1 x 3M VHB Tape
● Mounting hardware

Please refer to the detailed user manual below to assist you during your installation. It is the same material that is in the LED bulb box packaging.

We have created some installation examples to showcase the recommended steps you should take to make your upgrade a clean and fast install.

Download User Manual

If you have further questions or need technical assistance please call one of our knowledgeable tech support experts at (888) 608-2220 We are open Monday – Friday 9:00 a.m. – 5:00 p.m. CST

We can answer many of the common questions that arrive during a light upgrade.

ARC Lighting provides a 5 (Five) year warranty on all BUILTBRIGHT® products, for manufacturing defects or product failure. If you have an issue with any product, please report it to our authorized dealer or distributor where your product(s) were purchased. When directed to do so after you have spoken to the purchasing location you may file your claim with us directly using the online form below. If your product is determined to be defective in material or workmanship, ARC Lighting will issue an RMA number.
