| Light Output | 1,400 Lumens (Per Light) |
| LEDs | LP Modular LED (White) + Cree LED (Amber) |
| Power | 32W @ 13.6V DC |
| Current | 2.4A @ 13.6V DC |
| Voltage | 10 - 36V DC |
| IP Rating | IP67 |
| Dimensions | 1.6” x 6.1” x 2.3” |
| Beam Pattern | Fog + Strobe |
| Compliance | SAE J583 |
| Warranty | 3 Years |
Xtreme Series Bar, 6″ Street Legal, Fog Light w/ Amber Strobe Light – 61012
MSRP $386.16 USD
With the introduction of our Xtreme Bar street-legal light bars, we are redefining the auxiliary driving light category. Our new street legal light bars epitomize our commitment to maximizing light output and road safety with an innovative approach. The all new optical design not only produces a SAE-compliant beam pattern but also surpasses the power of the most off-road light bars. The versatility of combining driving, fog and emergency strobe beams together is a true innovation to give the best lighting you need on and off road.
MULTIFUNCTIONAL:
Versatile mounting options with available all-in-one high beam / fog / strobe light
STREET LEGAL:
SAE certified for use on any roadway in the USA
INNOVATIVE DESIGN:
Patented optics, low profile chassis and no-drill wiring harness
HIGH PERFORMANCE:
Power that surpasses most off-road light bars
2 x LED Light Bars
Side and Bottom Mounting Brackets & Hardware
1 x Wiring Harness
1 x Switch Panel
Please refer to the detailed user manual below to assist you during your installation. It is the same material that is in the LED bulb box packaging.
We have created some installation examples to showcase the recommended steps you should take to make your upgrade a clean and fast install.
Download User ManualIf you have further questions or need technical assistance please call one of our knowledgeable tech support experts at (888) 608-2220 We are open Monday – Friday 9:00 a.m. – 5:00 p.m. CST
We can answer many of the common questions that arrive during a light upgrade.
What are the differences between driving beam, fog beam, and off-road beam?
Are there both fog and strobe beams in this 6” Street Legal Light Bar Kit?
Are both side and bottom mounts included?
Is the wiring harness included?
Are there a pair of lights included in a kit?
Where do I find installation instructions and other technical information?
ARC Lighting provides a 3 (three) year warranty on all products, for manufacturing defects or product failure. If you have an issue with any product, please report it to our authorized dealer or distributor where your product(s) were purchased. When directed to do so after you have spoken to the purchasing location you may file your claim with us directly using the online form below. If your product is determined to be defective in material or workmanship, ARC Lighting will issue an RMA number.
After speaking to our technical support, please click here to file a warranty claim
